5000W 220V 60Hz Output LCD Display MPPT Solar Grid Tie Inverter

2 sold in last 8 hours
L03US5KWNBQ-1
In stock
$669.00
$669.00
Tags: / /

ECO-WORTHY

connect

1



Key Features

Integrated forming technology

No button design-knock to check

TUV Certification

LCD Display

Integrated forming technology No button design-knock to check TUV Certification LCD Display



solar inverter

DC INPUT
Maximum DC Input Wattage: 5200W
Single MPPT Maximum DC Input Wattage: 3000W
Single Array Maximum Short circuit current: 18A
Maximum DC Input Voltage: 550V
MPPT Maximum Input Current: 15A
Full Load MMPT Voltage Range: 175V-500V
Rated Voltage: 360V
Strating /Shutdown Voltage: 100V/120V

AC OUTPUT
Maximum AC Output Wattage: 5000W
Maximum AC Output Current: 24A
Rated AC Voltage /Voltage Range: 220V/176V-276V
Grid Frequency: 60hz
Current Distortion Rate: <3%
Size: 386*420*159mm
Weight: 17.5kg
Cooling Method: Nature Cooling
Topology: No transformer
Night Wattage Consumetion: < 0.5W
LCD Display: Backlight, 16*4 Grid imaging
Communication port: RS485/WIFI(Opitionnal)
AC Extension cable specification: 4 mm



Inverter Efficiency & Protection
Maximum Efficiency: 98.1%
MPPT Efficiency: 99.9%
Starting/Shutdown Voltage setting
DC insulation impedance monitoring
Ground fault protection
Grid monitoring
Ground fault current monitoring

How to Installation

1

2

3

4

Using the mounting frame as a template, drill 3 holes as illustrated in image Fix the mounting frame as the figure shows. Do not make the screws too close to the wall, leaving 2-4mm exposed instead Hang the inverter onto the mounting frame Lock screws into the bottom leg to fasten the inverter
