1170W 24V (6x195W) Complete MPPT Off Grid Solar Kit with 3kW/60A Hybrid Inverter + 2.4kWh Lithium

If efficiency, reliability and affordable are high on your wish list, ECO-WORTHY 1170W 24V expandable MPPT Solar Kit is an ideal choice.
ECO-WORTHY 195 Watt 12V Mono solar panel is backed by 25-year linear power guarantee.
ECO-WORTHY LiFePO4 Lithium Iron Phosphate Battery has twice the power, half the weight and lasts 8 times longer than a sealed lead acid battery.
All in one inverter Integrated with 60A/24V MPPT solar charge controller, 3000W pure sine wave inverter in one compact unit to let you enjoy the stable power from the sun and the utility grid to keep you powered under any circumstances.
ECO-WORTHY 1170W 24V MPPT Solar Kit can be used for several different purposes, including homes, cabins, etc. Whatever the kit is used for, you can rest assured that you are purchasing a quality system. If you have any questions regarding this product, please contact us info@eco-worthy.com.

Package Includes
6x Bifacial 195W Mono Solar Panel
1x All-in-one Inverter(3000W 24V Inverter+60A MPPT Controller)
1x 5M 12AWG Extension Cable with MC4
1x 5M 12AWG MC4-MC4 Extension Cable
6x Z Mounting Bracket
2x Y MC4 Connector
Battery Options-
2.4kWh Lithium Battery (optional)
with
1x 100Ah 24V LiFePO4 Lithium Battery

Bifacial 195W Monocrystalline Solar Panel

Rated Power: 195W	Solar Cell: Monocrystalline
Maximum/Peak Voltage(Vmp): 19.8V	Open Circuit Voltage(Voc): 23.7V
Short circuit current: 10.5A	Maximum current: 9.85A
Output Tolerance: ±3%	Temperate coefficient of Isc: (010+/-0.01)%/℃
Temperate coefficient of Voc: -(0.38+/-0.01)%/℃	Temperature range: －40℃～ +85℃
Frame: Aluminum alloy frame	Weight: 20.48 lbs(9.29 kg)
Size: 52.6x26.38x1.38in (1335*670*35mm)

All-in-one Inverter(3000W 24V Inverter+60A controller)

Solar Charging Mode
Solar Charge Mode: MPPT	PV Charging Rated current: 60A
Max Input Power: 1400W	Rated Battery Voltage: 24V
Invert Mode
Output Waveform: Pure Sine Wave	Rated Output Power: 3000W
Rated Battery Input Voltage: 24V	Rated Output: 110VAC 50Hz/60Hz
Peak Power: 6000W
AC/Grid Charging Mode
Rated Input: 110VAC 50Hz/60Hz(auto detect)

100Ah LiFePO4 Lithium Battery

Battery Capacity: 100Ah	Battery Power: 2560Wh
Battery Voltage: 25.6V	Maximum Charging Current: 80A
Maximum Discharging Current: 100A	Max Charge Voltage: 29.2V
Operating Temperature: -4°F to 140°F	BMS: Integrated battery management system
Terminal: M8 screw	Size: 14.6*7.87*10.8inch
Weight: 51.05lbs

16.4 feet 12AWG Cables

Cable Type: Connecting Solar Panels to Charge Controller	Rating Voltage: 600/1000V
Length: 5 meters（16 ft）	Conductor: Tinned copper wire
AWG: 11	Normal Cross Sectional Area of the Conductor (mm2): 4
Waterproof: IP 65 Protection	Temperature: -40°F to +185°F
Connector: MC4	Weight: 0.742KG

Z Mounting Brackets

4 pieces of Z shape solar panel brackets

8 pieces of stainless steel nuts and cap bolts

Y Branch Cable MC4 Connectors

Compatible with MC4 solar connector.

Easy installation for 2 solar panels connected in parallel.
